Bertolotto Internal Door – Geometrica (Lacquered)
The Bertolotto Millepunti collection interprets contemporary design with a dot-pattern decor that runs along the door leaf, creating a regular and refined texture. The lacquered internal doors are made with an opaque painting cycle and precision manufacturing for a uniform and durable surface. The micro-dot pattern adds depth and light, maintaining a minimalist aesthetic suitable for living rooms, sleeping areas, and contract spaces. Extensive customization: BP Colors palette and, upon request, RAL/NCS, with the possibility of swing, sliding, and flush-to-wall systems coordinated with frames and architraves. Millepunti combines elegance, functionality, and Made in Italy quality.
Technical Description – Millepunti Collection
-
Matt lacquered leaf: 3-coat paint cycle with a 10±5 gloss finish for chromatic uniformity and resistance; "Millepunti" decor achieved with regularly spaced micro-incisions routed across the entire surface.
-
Leaf structure (hollow core): reinforced 50 mm perimeter frame in finger-joint solid wood; interior with 100% recycled kraft paper honeycomb; external skins in 8 mm MDF suitable for routing.
-
Perimeter edges: IPER4BOARD in 10/10 ABS lacquered on all 4 sides, slightly rounded edge for protection against impacts and rising damp.
-
Frames and architraves: TR/L8 as standard; optional TKT L9/P85 (flush on pull side) and TKS L9/P100 (reverse on push side). MDF components with IDRO, CARB, FSC® standards.
-
Hardware: 3 concealed hinges adjustable on 3 axes; magnetic lock with silent latch and adjustable strike plate; unified Bertolotto key.
-
Standard dimensions: widths 600–900 mm; heights 2000/2100 mm. Custom sizes available on request.
-
Color finishes: BP Colors palette; RAL/NCS on request. NO-GERMS® antibacterial option where applicable.
-
Opening systems: swing; concealed sliding; external wall sliding; flush-to-wall, for minimal aesthetic continuity.
-
Coordinability: possibility of matching boiserie and transoms; for double doors, a continuous design of the dot pattern is provided.
Performance, Tests, and Compliance (Bertolotto Lacquer)
-
Emissions and sustainability: raw materials compliant with CARB/EPA, VOC management – Indoor Air Comfort; ISO 14001/9001/45001 certified systems; FSC® MDF components.
-
Resistance to cold liquids (UNI EN 12720): on lacquered leaf, values up to class 5 for water/detergent solution; excellent resistance to 48% alcohol and common beverages.
-
Resistance to heat/scratches/impacts: dry/wet heat (UNI EN 12721) compliant with domestic use; scratches UNI EN 15185 and impacts UNI EN 15186 tested.
-
Mechanical durability: hollow core door test with 100,000 opening/closing cycles passed with compliant results.
-
Acoustic comfort (optional): packages up to 29 dB with NO-SOUND mobile threshold and dedicated gaskets; advanced solutions available on request.
