Bertolotto Internal Door – Geometrica (Lacquered)
The Bertolotto Millepunti collection interprets contemporary design with a dot-patterned decoration that runs along the door leaf, creating a regular and refined texture. The lacquered internal doors are made with an opaque painting cycle and precision processing for a uniform and durable surface. The micro-dot pattern adds depth and light, while maintaining a minimal aesthetic suitable for living areas, sleeping areas, and contract spaces. There is extensive customization: BP Colors palette and, upon request, RAL/NCS, with the possibility of swing, sliding, and flush-to-wall systems coordinated with frames and architraves. Millepunti combines elegance, functionality, and Made in Italy quality.
Technical Description – Millepunti Collection
-
Opaque lacquered door leaf: 3 coats of paint with a 10±5 gloss finish for chromatic uniformity and resistance; "Millepunti" decoration obtained with pantographed punctual micro-engravings at a regular pitch over the entire surface.
-
Door leaf structure (hollow core): enlarged 50 mm perimeter frame in finger-joint solid wood; honeycomb interior in 100% recycled kraft paper; exterior skins in 8 mm MDF suitable for pantographing.
-
Perimeter edges: IPER4BOARD in 10/10 ABS lacquered on all 4 sides, slightly rounded edge for protection against impacts and rising damp.
-
Frames and architraves: TR/L8 as standard; optional TKT L9/P85 (flush with pull side) and TKS L9/P100 (reverse push). MDF components with IDRO, CARB, FSC® standards.
-
Hardware: 3 concealed hinges adjustable on 3 axes; magnetic lock with silenced latch and adjustable strike plate; unified Bertolotto key.
-
Standard dimensions: widths 600–900 mm; heights 2000/2100 mm. Custom sizes available upon request.
-
Color finishes: BP Colors palette; RAL/NCS upon request. Optional NO-GERMS® antibacterial where specified.
-
Opening systems: swing; concealed sliding; external wall sliding; flush-to-wall, for minimal aesthetic continuity.
-
Coordinability: possibility of matching boiserie and overlights; on double doors, the continuous design of the dot pattern is provided.
Performance, Tests, and Compliance (Bertolotto Lacquered)
-
Emissions and sustainability: raw materials compliant with CARB/EPA, VOC – Indoor Air Comfort management; ISO 14001/9001/45001 certified systems; FSC® MDF components.
-
Resistance to cold liquids (UNI EN 12720): on lacquered door leaf, values up to class 5 for water/detergent solution; excellent resistance to 48% alcohol and common beverages.
-
Resistance to heat/scratches/impacts: dry/wet heat (UNI EN 12721) compliant with domestic use; UNI EN 15185 scratches and UNI EN 15186 impacts tested.
-
Mechanical durability: test on hollow core door leaf with 100,000 opening/closing cycles passed with compliant results.
-
Acoustic comfort (optional): packages up to 29 dB with NO-SOUND mobile threshold and dedicated gaskets; advanced solutions available upon request.
