Bertolotto Internal Door – Geometrica (Lacquered)
The Bertolotto Millepunti collection interprets contemporary design with a dot-pattern decor that runs across the door leaf, creating a regular and refined texture. The lacquered internal doors are made with an opaque painting cycle and precision manufacturing for a uniform and durable surface. The micro-dot pattern adds depth and light, while maintaining a minimalist aesthetic suitable for living areas, sleeping areas, and contract spaces. Extensive customization: BP Colors palette and, upon request, RAL/NCS, with the possibility of swing, sliding, and flush-to-wall systems coordinated with frames and architraves. Millepunti combines elegance, functionality, and Made in Italy quality.
Technical Description – Millepunti Collection
-
Matte lacquered door leaf: 3-coat paint cycle with 10±5 gloss finish for chromatic uniformity and resistance; "Millepunti" decor obtained with pantographed point micro-engravings at regular intervals across the entire surface.
-
Door leaf structure (hollow core): reinforced 50 mm perimeter frame in finger-joint solid wood; honeycomb interior made of 100% recycled kraft paper; external skins in 8 mm MDF suitable for pantographing.
-
Perimeter edges: IPER4BOARD in 10/10 ABS lacquered on all 4 sides, slightly radiused edge for protection against impacts and rising damp.
-
Frames and architraves: standard TR/L8; optional TKT L9/P85 (flush pull side) and TKS L9/P100 (reverse push side). MDF components with IDRO, CARB, FSC® standards.
-
Hardware: 3 concealed hinges adjustable on 3 axes; magnetic lock with silent latch and adjustable strike plate; unified Bertolotto key.
-
Standard dimensions: widths 600–900 mm; heights 2000/2100 mm. Custom sizes available upon request.
-
Color finishes: BP Colors palette; RAL/NCS upon request. NO-GERMS® antibacterial option where applicable.
-
Opening systems: swing; concealed sliding; external wall sliding; flush-to-wall, for minimal aesthetic continuity.
-
Coordination: possibility of matching boiserie and fanlights; continuous design of the dot pattern provided on double doors.
Performance, Tests and Conformity (Bertolotto lacquered)
-
Emissions and sustainability: raw materials compliant with CARB/EPA, VOC management – Indoor Air Comfort; ISO 14001/9001/45001 certified systems; FSC® MDF components.
-
Resistance to cold liquids (UNI EN 12720): on lacquered door leaf, values up to class 5 for water/detergent solution; excellent resistance to 48% alcohol and common beverages.
-
Heat/scratch/impact resistance: dry/wet heat (UNI EN 12721) compliant with domestic use; scratches UNI EN 15185 and impacts UNI EN 15186 tested.
-
Mechanical durability: hollow-core door leaf tested with 100,000 opening/closing cycles passed with compliant results.
-
Acoustic comfort (optional): packages up to 29 dB with NO-SOUND mobile threshold and dedicated gaskets; advanced solutions available upon request.
