Bertolotto Internal Door – Double-Sided Fusion
The Bertolotto Fusion collection is born from the combination of Laminam ceramic slabs and high-quality wood surfaces, creating interior doors that perfectly coordinate with the home's ceramic coverings. The concept, inspired by nature, enhances volume, material, and luster with contemporary textures and a great tactile feel. The doors are made with a big structure and enlarged 50 mm spruce slats to ensure long-term stability, and are edged on all 4 sides with IPER4BOARD in 10/10 ABS for moisture protection and precise edge finishing. A wide selection of ceramic finishes and configurations (swing, sliding, flush) are available for residential and contract projects focused on design, durability, and material coherence.
Technical Description – Fusion Collection
-
Door panel: big structure with enlarged 50 mm spruce slats for high long-term stability and reduced risk of deformation/warping. :contentReference[oaicite:0]{index=0}
-
Cladding: inserts in Laminam ceramic slabs combined with high-quality wood surfaces, for material continuity with interior coverings. :contentReference[oaicite:1]{index=1}
-
Edging: 4-sided edging with IPER4BOARD in 10/10 mm ABS, moisture protection, and high-precision rounded edge finish. :contentReference[oaicite:2]{index=2}
-
Supports and skins: technical hollow-core panel with a honeycomb core and skins suitable for bonding ceramic slabs (surface quality and flatness for optimal adhesion). :contentReference[oaicite:3]{index=3}
-
Frames and architraves: TR/L8, TKT L9/P85 (flush pull side), and TKS L9/P100 (reverse push side) options, in MDF with Bertolotto environmental and quality standards. :contentReference[oaicite:4]{index=4}
-
Finishes: wide range of Laminam ceramic textures (marbles, stones, concretes, metals) coordinated with the interior design; doors available in multiple configurations and opening types. :contentReference[oaicite:5]{index=5}
-
Scope of use: solutions for residential and contract requiring surface resistance, ease of cleaning, and aesthetic-material coherence with floors and coverings. :contentReference[oaicite:6]{index=6}
Performance, tests, and compliance (Bertolotto lacquered)
-
Emissions and sustainability: FSC®, CARB/EPA certified materials; low-impact water-based paints; VOC programs for indoor air quality.
-
Resistance to cold liquids (UNI EN 12720:2011, lacquered leaf): class 5 for water, detergent, saline solution; excellent resistance to 48% ethyl alcohol and common beverages.
-
Resistance to dry/wet heat (UNI EN 12721:2009); scratch resistance (UNI EN 15185) and impact resistance (UNI EN 15186) tested for domestic use.
-
Mechanical durability: 200,000 opening/closing cycles on a finished door.
-
Acoustic insulation: on request, 29 dB package with NO-SOUND automatic threshold and dedicated gaskets.
